Product Summary
The MD-2811-D32-V3-X is a member of M-Systems’ DiskOnChip product series. A single die (16/32MB) with embedded flash controller and flash memory, MD-2811-D32-V3-X provides a complete, easily integrated flash disk for highly reliable data and code storage. The MD-2811-D32-V3-X also offers advanced features for hardware protected data and code and security-enabling features for both data and code storage.
Parametrics
MD-2811-D32-V3-X absolute maximum ratings: (1)DC Core Supply Voltage, VCC: -0.6 to 4.6V; (2)DC I/O Supply Voltage, VCCQ3: -0.6 to 4.6V; (3)Input Pin Voltage, VIN: -0.6 to VCCQ+0.3, 4.6V max; (4)Input pin Current, IIN: -10 to 10mA; (5)Storage Temperature, TSTG: -55 to 150℃; (6)Lead Temperature, TLEAD: 260℃; (7)Maximum duration of applying VCCQ, without VCC or VCC without VCCQ, Tsupply: 500mS.
Features
MD-2811-D32-V3-X features: (1)Advanced protection and security-enabling features for data and code; (2)Proprietary TrueFFS technology for full hard-disk emulation, high data reliability and maximum flash lifetime; (3)Device cascade options for up to 128MByte (1Gbit) capacity; (4)Small form factors: 48-pin TSOP-I and 69-ball BGA; (5)NAND-based flash technology that enables high density and small die size; (6)Single-die chip: 16MByte and 32MByte, dual-die chip: 64MByte; (7)Exceptional read, write and erase performance; (8)Configurable for 8/16/32-bit bus interface; (9)Programmable eXecute In Place (XIP) Boot Block; (10)Data integrity with Reed-Solomon-based Error; (11)Deep Power-Down mode for reduced power consumption; (12)Low voltage; (13)Software tools for programming, duplicating, testing and debugging; (14)Support for all major OSs, including: Symbian OS, VxWorks, Windows CE, Linux, pSOS and QNX.
Diagrams
