Product Summary

The AUIRFS3107 is a HEXFET Power MOSFET. Specifically designed for Automotive applications, the AUIRFS3107 utilizes the latest processing techniques to achieve extremely low on-resistance per silicon area. Additional features of this design are a 175℃ junction operating temperature, fast switching speed and improved repetitive avalanche rating . These features combine to make this design an extremely efficient and reliable device for use in Automotive applications and a wide variety of other applications.

Parametrics

AUIRFS3107 absolute maximum ratings: (1)ID @ TC = 25℃ Continuous Drain Current, VGS @ 10V (Silicon Limited): 230A; (2)ID @ TC = 100℃ Continuous Drain Current, VGS @ 10V (Silicon Limited): 160A; (3)ID @ TC = 25℃ Continuous Drain Current, VGS @ 10V (Package Limited): 195A; (4)IDM, Pulsed Drain Current: 900A; (5)PD @TC = 25℃ Maximum Power Dissipation: 370W; (6)VGS, Gate-to-Source Voltage: ± 20V; (7)EAS, Single Pulse Avalanche Energy (Thermally Limited): 300mJ; (8)dv/dt, Peak Diode Recovery: 14V/ns; (9)TJ, Operating Junction and TSTG, Storage Temperature Range: -55 to + 175℃; (10)Soldering Temperature, for 10 seconds (1.6mm from case): 300℃.

Features

AUIRFS3107 features: (1)Advanced Process Technology; (2)Ultra Low On-Resistance; (3)Enhanced dV/dT and dI/dT capability; (4)175℃ Operating Temperature; (5)Fast Switching; (6)Repetitive Avalanche Allowed up to Tjmax; (7)Lead-Free, RoHS Compliant; (8)Automotive Qualified.

Diagrams

AUIRFS3107 circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
AUIRFS3107
AUIRFS3107

International Rectifier

MOSFET 75V 230A 3 mOhm Automotive MOSFET

Data Sheet

0-1: $2.08
1-25: $1.66
25-100: $1.30
100-250: $1.23
AUIRFS3107-7P
AUIRFS3107-7P

International Rectifier

MOSFET 75V 260A 2.6 mOhm Automotive MOSFET

Data Sheet

0-1: $2.23
1-25: $1.78
25-100: $1.39
100-250: $1.32
AUIRFS3107TRL
AUIRFS3107TRL

International Rectifier

MOSFET 75V 230A 3 mOhm Automotive MOSFET

Data Sheet

0-620: $1.19
620-800: $1.19
AUIRFS3107TRR
AUIRFS3107TRR

International Rectifier

MOSFET 75V 230A 3 mOhm Automotive MOSFET

Data Sheet

0-620: $1.19
620-800: $1.19
AUIRFS3107-7TRR
AUIRFS3107-7TRR

International Rectifier

MOSFET 75V 260A 2.6 mOhm Automotive MOSFET

Data Sheet

0-620: $1.27
620-800: $1.27
AUIRFS3107-7TRL
AUIRFS3107-7TRL

International Rectifier

MOSFET 75V 260A 2.6 mOhm Automotive MOSFET

Data Sheet

0-800: $1.27
800-6180: $1.27
