Product Summary
The PA95 is a high voltage, MOSFET operational amplifierdesigned as a low cost solution for driving continuous outputcurrents up to 100mA and pulse currents up to 200mA intocapacitive loads. The safe operating area (SOA) has nosecond breakdown limitations and can be observed for all loadtypes by choosing an appropriate current limiting resistor. TheMOSFET output stage is biased AB for linear operation.External compensation provides flexibility in choosing band-width and slew rate for the application. APEX’s Power SIP04package uses a minimum of board space allowing for highdensity circuit boards.
Features
? HIGH VOLTAGE — 900V (±450V)
? LOW QUIESCENT CURRENT — 1.6mA
? HIGH OUTPUT CURRENT — 100mA
? PROGRAMMABLE CURRENT LIMITAPPLICATIONS
? HIGH VOLTAGE INSTRUMENTATION
? PROGRAMMABLE POWER SUPPLIES UP TO±430V
? MASS SPECTROMETERS
? SEMICONDUCTOR MEASUREMENT EQUIPMENT
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201262944944267.jpg"><IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201262944944315.jpg"><IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201262944944341.jpg"><IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201262944944921.jpg"><IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201262944944754.jpg">
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PA95 |
Cirrus Logic |
Operational Amplifiers - Op Amps Linear Op-Amp 900V 100mA |
Data Sheet |
Negotiable |
|
|||||||||||||
PA951 |
Carling Technologies |
Pushbutton Switches SP ON-OFF .250 Q.C. |
Data Sheet |
|
|
|||||||||||||
PA955 |
Carling Technologies |
Pushbutton Switches PB SWITCH ON-OFF |
Data Sheet |
|
|
|||||||||||||
PA95EC |
Cirrus Logic |
Operational Amplifiers - Op Amps Linear Op-Amp 900V 100mA |
Data Sheet |
Negotiable |
|
