Product Summary
The AT49F1024-POVC is a 5-volt-only in-system Flash memory. It is organized as 65,536 words by 16 bits. Manufactured with Atmel’s advanced nonvolatile CMOS technology, the AT49F1024-POVC offers access times to 45 ns with power dissipation of just 275 mW over the commercial temperature range. When the AT49F1024-POVC is deselected, the CMOS standby current is less than 100μA. To allow for simple in-system reprogrammability, the device does not require high input voltages for programming.
Parametrics
AT49F1024-POVC absolute maximum ratings: (1)Temperature Under Bias:-55℃ to +125℃; (2)Storage Temperature:-65℃ to +150℃; (3)All Input Voltages(including NC Pins) with Respect to Ground:-0.6V to +6.25V; (4)All Output Voltages with Respect to Ground:-0.6V to VCC + 0.6V; (5)Voltage on OE with Respect to Ground:-0.6V to +13.5V.
Features
AT49F1024-POVC features: (1)Single Voltage Operation:5V Read, 5V Reprogramming ; (2)Fast Read Access Time:45 ns ; (3)Internal Program Control and Timer ; (4)8K word Boot Block With Lockout ; (5)Fast Erase Cycle Time:10 seconds; (6)Word By Word Programming:10μs/Word Typical; (7)Hardware Data Protection ; (8)DATA Polling For End Of Program Detection ; (9)Small 10 x 14 mm VSOP Package; (10)Typical 10,000 Write Cycles.
Diagrams
 |
